Máy đo độ cứng siêu âm hãng ACEPOM ACEPOM6811

    • Liên hệ báo giá:
    • SĐT: 0948.007.822
    • Mail:
      • Zalo: 0948.007.822

Thông tin sản phẩm

Máy đo độ cứng siêu âm hãng ACEPOM ACEPOM6811

It has the following characteristics:

No damage to the workpiece - no visible indentation on the surface of the workpiece

High measurement accuracy - up to ±1.0 HRC, or ±3%HV/HB

Fast measurement speed -- output test results within 1 second, suitable for full on-site inspection of large quantities of products

Stable performance - has been used in many domestic industries leading large Chinese and foreign famous enterprises

Wide test range - up to 1700HV

Can measure thin workpieces - such as chromium plating, nitriding, carburized surface, thin plate, thin wall tube, etc

Non - impact, can be measured gear, crankshaft, slewing bearings and other irregular shape of the workpiece

Bulk storage - 999 sets of measurements can be stored automatically

Wireless bluetooth printing - a miniature bluetooth printer can be configured to print test results on site

USB interface - can be connected to the computer through data software

Adaptive multiple probe (5 n probe, 30 n probe, Φ 4 mm small diameter probe), so as to adapt to different workpiece measurement requirements.

ACEPOM6811 portable ultrasonic hardness tester is using the ultrasonic vibration principle to measure the hardness of a new type of intelligent instrument, it is mainly used for measuring metal rockwell hardness (HRC), vickers hardness (HV), brinell hardness (HB), and automatic storage function with data and function of bluetooth print, is currently the portable hardness tester, the only hardness tester of workpiece surface without damage.

Applicable objects:

ACEPOM6811 portable ultrasonic hardness tester can be adapted to the field of fine grain materials of any shape and size of the workpiece, in electroplating, mechanical processing, automotive parts, aerospace, petrochemical, heat treatment, mold, bearing, crankshaft, gear, supervision and inspection and scientific research teaching and other fields are widely used including:

Electroplating, nitriding, carburizing, sheet or sheet metal, small parts and other portable hardness tester can not measure the workpiece
