Measure the oxygen concentration profile in the furnace.

Yêu Cầu Giá Tốt

Thông tin sản phẩm

Item Specification
Model Name RCX-O
Main Unit RCM-O
Max. measuring time Ni-MH battery: Approx. 40min.
Sampling time 0.05sec. 0.1sec. 0.2sec. 0.5sec. 1.0sec. 2.0sec. 4.0sec. 8.0sec.
Arbitrary setup possible (synchronized to RCM-S memory unit)
Oxygen Measurement principle Zirconia limiting current method
Measurement range 50ppm~5000ppm
Measurement accuracy 50ppm~1000ppm±5%FS
Power supply Supplied from RCM-S Memory unit
Ni-MH battery (AAA battery x 3)
Outer dimensions 65(W)×383(D)×25(H)(㎜) Excluding projections
Weight Approx. 950g (including battery, tray is not included)

  • * The maximum measuring time is a time in which heat resistance is not considered, and it cannot be measured
         in the reflow oven.
  • * Manganese batteries and alkaline batteries are not available.
  • * Lithium-ion secondary battery or AAA battery is selectable at the time of order.
  • * The above specifications are subject to change without notice.
