Mã sản phẩm: RCM-S
Sử dụng cho Model:
Hãng SX: Malcom
Xuất xứ
Bảo hành
Tình trạng

Tình trạng: Còn hàng

Đặt hàng

● Temperature measured in units of the underlying system.
● New features such as Bluetooth, OK/NG judgment function, Thermocouple response and AAA batteries.

Yêu Cầu Giá Tốt

Thông tin sản phẩm

Item Specification
Model Name RCX-S
Main Unit RCM-S
Measuring Temp. Range 0~500℃ *1
Max Measuring Time Approx. 10 hours * 1 * 2
Sampling Time (sec.) /Max. Storage Time 0.05sec./4h50min, 0.1sec./10h40min, 0.2sec./21h20min, 0.5sec./48h20min, 1.0sec/96h40min, 2.0sec./193h20min, 4.0sec/386h40min, 8.0sec./773h20min Arbitrary setup possible
Temperature Accuracy ±1℃
Measuning Points 1-6 Points
Heat Resistant Connector Miniature Connector
Input Thermocouple JIS-K 1kΩ max.
0.1 10m
Power Supply AAA battery
Manganese batteries Alkaline battery Nickel-metal hydride
Outer dimensions Memory unit (w/o Heat resistant case) 55 (W) x 170 (D) x 18 (H) mm 200g
Heat resistant case: 65 (W) x 245 (D) x 25 (H) mm 370g
Data Transmission Method USB, Bluetooth
Weight Approx. 570g (Heat resistant case and battery are included)
  • * 1 It differes from the heat resistant time of memory unit.
  • * 2 It is the experimental value by AAA battery. The max. measuring time depens on battery capacity.
  • * The above specifications are subject to change without notice.
