| Accuracy |
+/- 1% of full scale |
| Alarm Type |
Flashes red LED once every 8 seconds |
| Battery |
3.6 volt Lithium |
| Case Material |
Noryl® plastic (All models) |
| Clock Accuracy |
+/- 2 seconds per day |
| Communication |
Optical data transfer; data can be transmitted through glass or transparent medium up to 25 mm (1in) |
| Input Impedance |
100 ohms |
| Input Range |
0 to 24 mA DC |
| Memory Size |
32 KB |
| Operating Limits |
-40 to 70°C (-40 to 158°F) and 0 to 95% RH (non-condensing |
| PC Requirements |
Windows PC with a least 256MB RAM, 250MB of hard drive space and one free serial or USB port. |
| Resolution |
8-bit (1 part in 256) |
| Sampling Method |
Continuous (First-in, First-out)*, Stop When Full (Fill-then-stop)
*Not available for sample rates faster than 8 seconds |
| Sampling Rate |
User selectable rates from 5 per second to once every 12 hours |
| Size |
60 x 48 x 19 mm (2.4 x 1.9 x 0.7 in) |
| Weight |
54 g / 1.9 oz (All models) |
