Standards
|
JIS K 6253
JIS K 7215
ASTM D 2240
ISO 7619
ISO 868
DIN 53505
|
|
Indication range
|
0 point - 100 point (262 degree dial scale)
|
|
Minimum indication
|
1 point (Accuracy : ±1 point)
|
|
Indentor Design (mm)
|
Height: 2.50 35°Angle Flat Cone Point 0.79 Dia.
|
|
Spring Forces [mN(g)]
|
0 point: 550(56)
100 point: 8050(821)
|
|
Central hole of diameter of Pressure foot
|
Φ3
|
|
Pressure foot
Dimension (mm)
|
Φ12 Longer foot type Length: 18
|
|
Outer Dimension (mm)
|
Approx. Width 57×Depth 30×Height 94
|
|
Weight (g)
|
200
|
|
Application
|
general rubber, soft plastic
|
