TP200 with SCR20 and PI 200-3
The TP200 system components are:
TP200 or TP200B probe body (the TP200B is a variant with increased vibration tolerance)
TP200 stylus module - choice of fixed overtravel forces: SF (standard force) or LF (low force)
PI 200-3 probe interface
SCR200 stylus change rack
There is also an EO module (extended overtravel) which has the same overtravel force as the SF but provides increased operating range and protection in the probe Z-axis.
Features and benefits
Strain-gauge technology offers excellent repeatability and precision 3D form measurement
Zero reseat errors
No lobing effect
6-way measuring capability
Stylus reach of up to 100 mm (GF styli)
Rapid probe module changing without the need to re-qualify the stylus tips
Life of >10 million triggers
