Self-developed measuring software QMS3D-M and imported HD 1/2" color camera.
The software can also be used to adjust the brightness, enabling the user to learn whether the light is over-saturated.
Detects the measured workpiece’s specific location by laser indicator, which is quick to position, and convenient to operate.
Stationary working table and granite pedestal, which are reliable, heavy loading and high precision.
X and Y axes adopt air bearing and granite guide, ensuring a precision and stable mechanical system, and improving measuring accuracy.
Height aided measurement available.
Linear Scale resolution: 0.5μm
Foot-switch matched with measuring software, which makes operation easier.
Thông số kỹ thuật
