| Accuracy |
±0.2％F.S 1digit |
| Unit |
N(mN,kN) , kg(g), lbf （*1） |
| Display |
Signed 4-digit LCD |
| Sampling rate |
Max. 1000 data / sec (1000Hz) |
| Battery |
Approx.30 hours (when back light is off) Approx. 14 hours (when back light is on) (*needs 4.5 hours for full charge) |
| Overload |
Approx. 200％F.S. |
| Power |
Nickel-Metal Hydride battery (NiMH battery), USB charge (PC, mobile battery, AC adapter) |
| Operating environment |
Temperature：0 – 40℃ Humidity：20 – 80％RH |
| Function |
Peak hold(Tensile or compression)/Comparator(OK Judgement)/Sensitivity(3 steps)/Reversible display /Sign inversion/Setting lock/Date & Time/Off timer (Auto power-off)/Reminder for calibration schedule/Overload alarm |
| Output |
USB/RS232C |
| Overload alarm |
Alarm to notify “near-overload state”: Approx.90%F.S. (Alarm sound) Alarm to notify “overloaded state”: Approx.110%F.S. (Alarm sound/Indication blinking) |
| Weight |
Approx.460ｇ （*2） |
| Dimensions |
Refer to Dimensions below. |
| Accessory |
Force Logger(Data capturing software)／USB cable／ ACAdapter／Attachment（*3）／Carrying case／Instruction manual／Inspection certificate |
