Model AV-1020-C is a full-featured, 10 MHz high-performance general-purpose lab pulse generator providing 0 to ±10 Volts, 10 ns rise time, single and double-pulse modes, variable DC offset, variable delay, ECL and TTL outputs (and their complements!), self-explanatory front panel controls and a heavy-duty metal chassis for low emissions and decades of trouble-free service. This is a versatile, cost-effective pulse
source for many digital and analog applications in industrial and academic fields.
The output amplitude is controlled by a 3 position range switch (1, 5 and 10 Volts) and a one-turn control. Output polarity is controlled by a two-position switch. 50 Ohm back-matching is provided for the 1 and 5 Volt ranges.
A one-turn control allows the variation of the base line or DC offset from 0 to ±10 Volts.
The output pulse width (and delay) is variable from 50 ns to 0.5 sec via a seven-position range switch and a one-turn control. The pulse width may also be set to the "DC" mode, allowing the AV-1020-C to be used as a variable ±10 Volt, 200 mA DC power supply.
Thông số kỹ thuật
