The AV-1015-B is Avtech's general-purpose ±50V pulse generator, and the AV-1010-B is the generalpurpose ±100V model. These models will operate into loads of 50 Ω or higher, and they offer 10 ns rise and
fall times (20%-80%).
The more-specialized AV-1011B1-B and AV-1011B3-B models offer faster rise and fall times (100V / 2 ns for the AV-1011B1-B, and 30V / 0.5 ns for the AV-1011B3-B). These faster models require a 50 Ω load.
Model AV-1010-B is a fully-featured general-purpose instrument that can be controlled from the userfriendly front-panel keypad and LCD, or by the IEEE-488.2 GPIB and RS-232 computer-control ports. The
amplitude of the AV-1010-B can be varied up to ±100V, and the pulse width is adjustable from 20 ns to 10 ms. The output impedance (i.e., the internal resistance in series with the output) can be switched
between 2 Ω and 50 Ω (regardless of the output impedance setting, the load impedance must be 50Ω or higher). The rise and fall times are fixed at less than 10 ns (20%-80%).
Thông số kỹ thuật
