* A/D conversion method integrating ultra-high-speed
* Measuring value is displayed in percentage against the reference capacitance value set digitally and comparison result by built-in comparator is displayed as -NG, GO, +NG by LED and buzzer.
* Measuring range：100nF～9.99mF/－79.9％～＋99.9％
* 4-terminal measurement
* BCD parallel out available
* External bias can be applied (max.DC25V)
Thông số kỹ thuật
Click xem ngay >>> High Speed, high accuracy 120kHz Digital Capacitance Checker AX-3121A ADEX
