- Low-ESR/Low-impedance measuring range: 100mΩ～100Ω range.
- Resolution：10μΩ (ESR)
- Available to make the Contact･Check to watch the contact condition of Probe. Contact.
- 4 digit display and LO/GO/HI/ Contact･Error Output.
- Measurement of low-equivalent series resistance and low-impedance on 100kHz at high-stablility･high-accuracy･high-speed.
- By RS-232C or GP-IB, all functions can be controlled externally (Option)
- Printer output (Option)
Thông số kỹ thuật
