- Temperature compensation [0ppm/℃～9999ppm/℃]
(Sensor：Option ￥12,000)
- Measurement not to influenced by thermal electro motive force.
- Contact-check is equipped as standard function
- GP-IB/RS-232C/Centoronics output available. (Option)
- Measuring range：0.00mΩ～15.000MΩ
- 4-terminal measurement
- Available to measure the persent the set reference value:
5mΩ～10MΩ±50.0％ [Minimum resolution：5μΩ]
- Comparison result by built-in comparator is open-collector output and displayed as LO, GO, HI by LED and buzzer.
Thông số kỹ thuật
