The AVN series provides high-amplitude (to 30V) pulses with very fast rise and fall times (as low as 100 ps) at repetition rates up to 200 MHz. Model AVN-W2-C operates from 10 to 75 MHz, generating amplitudes of up to 8V. The rise times are 200 ps. Below 40 MHz, the pulse width may be adjust from 1 to 10 ns. Above 40 MHz, the pulse width range is limited to 1 to 5 ns. Model AVN-W1-C operates from 20 to 100 MHz, generating amplitudes of up to 5V with pulse widths variable from 0.2 to 2.5 ns (1.2 ns above 70 MHz). The rise time is 100 ps. The AVN-1-C operated at repetition rates between 25 and 200 MHz, with 100 ps rise time. The AVN-1- C offers amplitudes to 5V, with a 0.2-1 ns pulse width range.
Thông số kỹ thuật
